INSERT

Overview

The INSERT statement allows you to add new nodes and edges into the graph using node and edge patterns.

Different from graph pattern matching, INSERT supports variable declarations, label/schema expressions, and property specifications in node and edge patterns; while WHERE clauses are not allowed. Only basic concatenations of node and edge patterns are permitted, and the indication of edge direction is necessary.

Ultipa supports both closed graphs and open graphs. Their data insertion syntax is similar, but with important differences in requirements.

Closed Graph

For a closed graph, any node or edge inserted must conform to its defined graph type. Nodes or edges with undefined schemas or properties cannot be added.

You must assign exactly one schema to a node or edge in a closed graph. Any given property value will be checked against the defined value type; any property not explicitly provided defaults to null.

To create a closed graph:

GQL
CREATE GRAPH g1 {
  NODE User ({name STRING, gender STRING}),
  NODE Club (),
  EDGE Follows ()-[{since DATE}]->(),
  EDGE Joins ()-[{fee UINT32}]->()
}

Learn more about closed graphs →

Open Graph

For an open graph, you can directly insert nodes and edges, and the labels and properties are created on the fly.

You may assign zero, one, or multiple labels to a node or edge in an open graph. Each node or edge has its own set of properties.

To create an open graph:

GQL
CREATE GRAPH g2 ANY

Learn more about open graphs →

Inserting Nodes

Nodes are inserted using node patterns.

To insert a single User node:

GQL
INSERT (:User {name: "claire", gender: "female"})

To insert multiple nodes and return them:

GQL
INSERT (n1:User {_id: "U2", name: "Quasar92"}),
       (n2:Club {_id: "C1"}),
       (n3:Club)
RETURN n1, n2, n3

In an open graph, you may assign multiple labels to a node:

GQL
INSERT (n:Person&Employee {name: "Bob"})
RETURN n

Inserting Edges

Edges are inserted using edge patterns, which connect nodes on both ends and include a direction to indicate source and destination.

To insert two User nodes and a Follows edge between them:

GQL
INSERT (:User {name: 'rowlock'})-[:Follows {since: date('2024-01-05')}]->(:User {name: 'Brainy', gender: 'male'})

To insert an edge between existing nodes, first retrieve the nodes using MATCH:

GQL
MATCH (n1:User {name: 'claire'}), (n2:Club {_id: 'C1'})
INSERT (n1)-[e:Joins {fee: 1200}]->(n2)
RETURN e

To insert a Joins edge from an existing User node to a new Club node:

GQL
MATCH (user:User {name: 'Quasar92'})
INSERT (user)-[:Joins]->(:Club {_id: "C2"})

Inserting Graph

To insert the nodes and edges shown above, consider it as two paths intersecting at the Club node:

GQL
INSERT (:User {name: 'waveBliss'})-[:Joins]->(c:Club {_id: 'C3'}),
       (:User {name: 'bella'})-[:Joins]->(c)<-[:Joins]-(:User {name: 'Roose'})

Alternatively, you can insert each node and edge individually:

GQL
INSERT (waveBliss:User {name: 'waveBliss'}),
       (bella:User {name: 'bella'}),
       (Roose:User {name: 'Roose'}),
       (C3:Club {_id: 'C3'}),
       (waveBliss)-[:Joins]->(C3),
       (bella)-[:Joins]->(C3),
       (Roose)-[:Joins]->(C3)

Property Value Examples

Ultipa supports a wide range of property types. You can view the complete list at here.

Below are examples of property values for different types. These examples assume a typed graph, where properties are explicitly defined with specific types. In open graphs, property value types are open too, but the examples can still serve as a useful reference for assigning values.

Numeric Properties

Numeric property value types include INT (INT32), UINT (UINT32), INT64, UINT64, FLOAT, DOUBLE, and DECIMAL(<precision>, <scale>).

GQL
// age is UINT32, weight is DECIMAL(10,2)
INSERT (:Person {age: 34, weight: 60.3})

Textual Properties

Textual property value types include STRING and TEXT.

GQL
// name is STRING
INSERT (:Person {name: "John Doe"})

Temporal Instant Properties

Temporal instant property value types include DATE, LOCAL DATETIME, LOCAL TIME, ZONED DATETIME, ZONED TIME, TIMESTAMP, and DATETIME.

GQL
// register is ZONED DATETIME, lastLogin is timestamp
INSERT (:Person {
    register: zoned_datetime("2025-01-01 12:20:02+0200"),
    lastLogin: 1762338059
})

Temporal Duration Properties

Temporal duration property value types include DURATION(YEAR TO MONTH) and DURATION(DAY TO SECOND).

GQL
// ativeDuration is DURATION(DAY TO SECOND)
INSERT (:Person {ativeDuration: "P526DT23H14M8S"})

Boolean Properties

Boolean property value type is BOOL.

GQL
// isBlocked is BOOL
INSERT (:Person {isBlocked: FALSE})

Spatial Properties

Spatial property value types include POINT and POINT3D.

GQL
// location is POINT, PoI is POINT3D
INSERT (:Person {
  location: POINT({latitude: 22.3, longitude: 125.6}),
  PoI: POINT3D({x: 10, y: 3.4, z: 6.2})
})

Record Properties

Record property value types is RECORD.

GQL
// bodyInfo is RECORD
INSERT (:Person {
  bodyInfo: {height: 175, weight: 68, bmi: 22.2, hairColor: "brown", bloodTyle: "O"}
})

Binary Properties

Binary property value types is BLOB.

GQL
// avatar is BLOB
INSERT (:Person {
})

List Properties

List property value type is LIST<subType>.

GQL
// tags is LIST<STRING>
INSERT (:Person {tags: ["IT", "happy", "geek"]})
