Overview
Katz Centrality measures the influence of a node by considering not only its immediate connections but also its indirect connections at various distances while diminishing importance to more distant nodes.
Katz centrality values range from 0 to 1, with higher scores indicating nodes that exert greater influence over the flow and connectivity of the network.
References:
- L. Katz, A New Status Index Derived from Sociometric Analysis (1953)
Concepts
Katz Centrality
The Katz centrality is an extension of the eigenvector centrality. In the k-th round of influence propagation in eigenvector centrality, the centrality vector is simply updated as c(k) = Ac(k-1), where A is the adjacency matrix. Katz centrality modifies this computation by introducing two additional parameters, leading to the following update formula (which should be rescaled afterward):
where,
α(alpha) is an attenuation factor that controls how influence decays during each propagation round. In thek-th round, the influences from indirect neighbors that areksteps away are considered, with their contributions cumulatively attenuated by a factor ofαk. To ensure the convergence ofc(k),αmust be smaller than1/λmax, whereλmaxis the dominant eigenvalue of the adjacency matrixA.β(beta) is a baseline centrality constant that ensures each node has a nonzero centrality score, even when it receives no influence. The common choice forβis 1.1is an n × 1 column vector of ones, where n is the number of nodes in the graph.
Example Graph
Run the following statements on an empty graph to define its structure and insert data:
ALTER GRAPH CURRENT_GRAPH ADD NODE {
web ()
};
ALTER GRAPH CURRENT_GRAPH ADD EDGE {
link ()-[{value float}]->()
};
INSERT (web1:web {_id: "web1"}),
(web2:web {_id: "web2"}),
(web3:web {_id: "web3"}),
(web4:web {_id: "web4"}),
(web5:web {_id: "web5"}),
(web6:web {_id: "web6"}),
(web7:web {_id: "web7"}),
(web1)-[:link {value: 2}]->(web1),
(web1)-[:link {value: 1}]->(web2),
(web2)-[:link {value: 0.8}]->(web3),
(web3)-[:link {value: 0.5}]->(web1),
(web3)-[:link {value: 1.1}]->(web2),
(web3)-[:link {value: 1.2}]->(web4),
(web3)-[:link {value: 0.5}]->(web5),
(web5)-[:link {value: 0.5}]->(web3),
(web6)-[:link {value: 2}]->(web6);
create().node_schema("web").edge_schema("link");
create().edge_property(@link, "value", float);
insert().into(@web).nodes([{_id:"web1"}, {_id:"web2"}, {_id:"web3"}, {_id:"web4"}, {_id:"web5"}, {_id:"web6"}, {_id:"web7"}]);
insert().into(@link).edges([{_from:"web1", _to:"web1",value:2}, {_from:"web1", _to:"web2",value:1}, {_from:"web2", _to:"web3",value:0.8}, {_from:"web3", _to:"web1",value:0.5}, {_from:"web3", _to:"web2",value:1.1}, {_from:"web3", _to:"web4",value:1.2}, {_from:"web3", _to:"web5",value:0.5}, {_from:"web5", _to:"web3",value:0.5}, {_from:"web6", _to:"web6",value:2}]);
Creating HDC Graph
To load the entire graph to the HDC server hdc-server-1 as my_hdc_graph:
CREATE HDC GRAPH my_hdc_graph ON "hdc-server-1" OPTIONS {
nodes: {"*": ["*"]},
edges: {"*": ["*"]},
direction: "undirected",
load_id: true,
update: "static"
}
hdc.graph.create("my_hdc_graph", {
nodes: {"*": ["*"]},
edges: {"*": ["*"]},
direction: "undirected",
load_id: true,
update: "static"
}).to("hdc-server-1")
Parameters
Algorithm name: katz_centrality
Name |
Type |
Spec |
Default |
Optional |
Description |
|---|---|---|---|---|---|
max_loop_num |
Integer | ≥1 | 20 |
Yes | The maximum number of iteration rounds. The algorithm terminates after all iterations are completed. |
tolerance |
Float | (0,1) | 0.001 |
Yes | The algorithm terminates when the changes in all scores between iterations are less than the specified tolerance, indicating that the result is stable. |
edge_weight_property |
"<@schema.?><property>" |
/ | / | Yes | A numeric edge property used as weights in the adjacency matrix A; edges without this property are ignored. |
direction |
String | in, out |
/ | Yes | Constructs the adjacency matrix A with the in-links (in) or out-links (out) of each node. |
alpha |
Float | (0, 1/λmax) | 0.25 |
Yes | The attenuation factor, which must be less than the inverse of dominant eigenvalue (λmax) of the adjacency matrix A. |
beta |
Float | >0 | 1 |
Yes | The baseline centrality constant that ensures every node has a nonzero centrality score. |
return_id_uuid |
String | uuid, id, both |
uuid |
Yes | Includes _uuid, _id, or both to represent nodes in the results. |
limit |
Integer | ≥-1 | -1 |
Yes | Limits the number of results returned; -1 includes all results. |
order |
String | asc, desc |
/ | Yes | Sorts the results by katz_centrality. |
File Writeback
CALL algo.katz_centrality.write("my_hdc_graph", {
return_id_uuid: "id",
max_loop_num: 50,
tolerance: 0.00001,
direction: "in",
alpha: 0.4
}, {
file: {
filename: "katz_centrality"
}
})
algo(katz_centrality).params({
projection: "my_hdc_graph",
return_id_uuid: "id",
max_loop_num: 50,
tolerance: 0.00001,
direction: "in",
alpha: 0.4
}).write({
file: {
filename: "katz_centrality"
}
})
Result:
_id,katz_centrality
web3,0.458447
web7,0.127183
web1,0.517601
web5,0.310561
web6,0.211972
web2,0.517601
web4,0.310561
DB Writeback
Writes the katz_centrality values from the results to the specified node property. The property type is double.
CALL algo.katz_centrality.write("my_hdc_graph", {
edge_weight_property: "@link.value"
}, {
db: {
property: "kc"
}
})
algo(katz_centrality).params({
projection: "my_hdc_graph",
edge_weight_property: "@link.value"
}).write({
db:{
property: 'kc'
}
})
Full Return
CALL algo.katz_centrality.run("my_hdc_graph", {
return_id_uuid: "id",
max_loop_num: 100,
tolerance: 0.00001,
edge_weight_property: "value",
direction: "in",
alpha: 0.4,
beta: 1,
order: "desc"
}) YIELD r
RETURN r
exec{
algo(katz_centrality).params({
return_id_uuid: "id",
max_loop_num: 100,
tolerance: 0.00001,
edge_weight_property: "value",
direction: "in",
alpha: 0.4,
beta: 1,
order: "desc"
}) as kc
return kc
} on my_hdc_graph
Result:
| _id | katz_centrality |
|---|---|
| web1 | 0.681081665151973 |
| web2 | 0.471519549878494 |
| web6 | 0.419136320993772 |
| web3 | 0.261956715748936 |
| web4 | 0.20956622151173 |
| web5 | 0.136218518184715 |
| web7 | 0.0838273050914304 |
Stream Return
CALL algo.katz_centrality.stream("my_hdc_graph", {
return_id_uuid: "id",
max_loop_num: 100,
tolerance: 0.00001,
edge_weight_property: "value",
direction: "in",
alpha: 0.4,
beta: 1,
order: "desc"
}) YIELD kc
RETURN kc
exec{
algo(katz_centrality).params({
return_id_uuid: "id",
max_loop_num: 100,
tolerance: 0.00001,
edge_weight_property: "value",
direction: "in",
alpha: 0.4,
beta: 1,
order: "desc"
}).stream() as kc
return kc
} on my_hdc_graph
Result:
| _id | katz_centrality |
|---|---|
| web1 | 0.681081665151973 |
| web2 | 0.471519549878494 |
| web6 | 0.419136320993772 |
| web3 | 0.261956715748936 |
| web4 | 0.20956622151173 |
| web5 | 0.136218518184715 |
| web7 | 0.0838273050914304 |
