# Total Neighbors

✓ File Writeback ✕ Property Writeback ✓ Direct Return ✓ Stream Return ✕ Stats

## Overview

The Total Neighbors algorithm computes the total number of distinct neighbors of two nodes as a measure of their similarity.

This algorithm takes into account the entire neighborhood of both nodes, giving a more comprehensive view of their similarity compared to algorithms that only focus on common neighbors. It is computed using the following formula:

where N(x) and N(y) are the sets of adjacent nodes to nodes x and y respectively.

More total neighbors indicate greater similarity between nodes, while a number of 0 indicates no similarity between two nodes.

In this example, TN(D,E) = |N(D) ∪ N(E)| = |{B, C, E, F} ∪ {B, D, F}| = |{B, C, D, E, F}| = 5.

## Considerations

• The Total Neighbors algorithm ignores the direction of edges but calculates them as undirected edges.

## Syntax

• Parameters:
Name
Type
Spec
Default
Optional
Description
ids / uuids []_id / []_uuid / / No ID/UUID of the first set of nodes to calculate; each node in ids/uuids will be paired with each node in ids2/uuids2
ids2 / uuids2 []_id / []_uuid / / No ID/UUID of the second set of nodes to calculate; each node in ids/uuids will be paired with each node in ids2/uuids2
type string Total_Neighbors Adamic_Adar No Type of similarity; for Total Neighbors, keep it as Total_Neighbors
limit int >=-1 -1 Yes Number of results to return, -1 to return all results

## Example

The example graph is as follows:

### File Writeback

Spec Content
filename node1,node2,num
uuids: [3],
uuids2: [1,5,7],
type: 'Total_Neighbors'
}).write({
file:{
filename: 'tn'
}
})

Results: File tn

C,A,3.000000
C,E,3.000000
C,G,3.000000

### Direct Return

Alias Ordinal Type
Description
Columns
0 []perNodePair Node pair and its similarity node1, node2, num
ids: 'C',
ids2: ['A','C','E','G'],
type: 'Total_Neighbors'
}) as tn
return tn

Results: tn

node1 node2 num
3 1 3
3 5 3
3 7 3

### Stream Return

Alias Ordinal Type
Description
Columns
0 []perNodePair Node pair and its similarity node1, node2, num
find().nodes() as n
with collect(n._id) as nID
ids: 'C',
ids2: nID,
type: 'Total_Neighbors'
}).stream() as tn
where tn.num >= 4
return tn

Results: tn

node1 node2 num
3 2 6
3 4 5
3 6 5
